Intelligent Control Terminal for Hazardous Chemicals (Cloud Console)

Product Introduction

The intelligent control terminal (cloud console) for hazardous chemicals is equipped with a self-developed "Intelligent Control System for the Whole Life Cycle of Hazardous Chemicals", which integrates recognition and electronic weighing modules. It can automatically identify reagent information and accurately weigh chemicals, and intelligently manage and record the storage, requisition, use, and disposal of chemicals, achieving intelligent ledger, risk warning, process tracing, and efficient management of chemical status.

Product Features


Product Parameters

Technical parameters

Size

Length 425x Width 400x Height 510mm

Display screen

13.3-inch capacitive touch screen

Tian Platform

Standard electronic balance with a range of 0-5kg and an accuracy of 0.01g (range and accuracy can be customized or connected to other electronic load-bearing devices)

AI Intelligence

The device supports facial recognition technology, which automatically recognizes user permissions and operation instructions

Material

Steel

Power switch

Push-button switch

Communication method

Supports multiple methods such as WIFI, network cables, Bluetooth, etc

Product Features

QR code system

RFID system

Model

ZZ64001

ZZ64002

Function

Identify reagent information through QR code electronic tags

Collect reagent information and real-time status inside the cabinet through RFID signal recognition device

Cloud Control Console (QR Code System) - Supporting Equipment

Model	Name	Specification
A60068	QR code label paper	57*35mm， 400 sheets/roll
A20051-37	Handheld barcode scanner (QR code version)	/
A10011-11	Portable Bluetooth electronic scale	/

Cloud Control Console (RFID System) - Supporting Equipment

Name	Specification
RFID Label Printer	60mm*300m， 1000 labels/roll
RFID Mobile handheld inventory counter	/
RFID Printer ribbon	50*25mm， 600 sheets/roll
RFID label paper	2000 sheets/roll

Optional system

Basic functions	Function details	QR code system	RFID system
Identity recognition	Facial/IC card recognition user permissions, automatic power on	√	√
Multi terminal operation	Supports both mobile and PC devices	√	√
Personnel Management	Support three-level permission division	√	√
ledger management	Support inventory statistics, ledger details, expense settlement, traceability management, etc., generate ledger and graphical charts	√	√
Data interoperability	Support integration with other systems and synchronization of data	√	√
Single Sign-On	Can intervene in the campus intranet and provide unified authentication	√	√
Risk Warning	Automatic warning of risks such as reagent mixing, environmental abnormalities, equipment abnormalities, overweight, and access control timeout, and push notifications	√	√
Voice prompt	Support voice prompt operation and warning	×	√
Environmental monitoring * optional	Self purifying exhaust gas, capable of monitoring temperature, humidity, VOC concentration, etc	√	√
Data recovery	When there is a malfunction, data can be restored	√	√
Data protection	Sensitive data can be encrypted, backed up, and restored to ensure security throughout the entire process	√	√
Internet	Supports RS485, WiFi, wired network	√	√
QR code recognition	Read reagent information by scanning the code	√	√
RFID automatic identification (cloud console)	No need for scanning, can read reagent information and weigh	×	√
RFID automatic identification (intelligent sub cabinet)	The storage area can recognize the status of reagents and issue warnings for violations	×	√
Storage cabinet management	An auxiliary cabinet that can be additionally connected to a live control lock	√	√
Storage cabinet management	Can be additionally connected to a sub cabinet without an electric control lock	√	×

Optional versions for each system

Advanced function	Stand-alone version	Online version	Process version
Query reagent data on the host and export it through USB interface	√	√	√
View data information for all cloud consoles, including the host	×	√	√
Built in 50000+chemical classification data, including 3700+chemical compatibility taboo classification catalog, 3700+chemical safety technical specifications, and SDS information can be queried	×	√	√
Query reagent status through mobile phone	×	√	√
Open system interface to capture data for smart systems	×	√	√
On the mobile end, in addition to other processes, a requisition process can also be carried out	×	×	√
